Example data plate car

Fig. 6.1. Examples of information signs with the data about the installed brakes

Arrow 1 - rear wheel brake - 1KF

Arrow 2 - front brake - 1LC

Sticker with vehicle data stored in the spare wheel well in the service book.

The following table shows the decoding numbers PR. They are important for combining bracket brake / brake disc / drum brake lining and brake shoe.
